RESIDENTIAL

JuiceBox Pro 48

JuiceBox Pro 48

JuiceBox 48 is a powerful, smart home charging station with an 11.5 kW (48 amps) maximum power output. It is especially suitable for drivers of electric cars with large battery packs, including performance and long-range Tesla models, and other EVs with high acceptance rates.

JuiceBox Pro 48

WiFi-enabled 48-amp smart EV charging station (Level 2 EVSE) with 25-foot cable & integrated cable management, hardwired installation

JuiceBox provides reliable and cost-effective charging to thousands of satisfied EV drivers and is the only line of charging stations that affords both direct user control and smart grid optimization through our software platform.

Offering a balance of power, safety, and convenience, JuiceBox 48 automatically adjusts to an EV’s accepted power level. The maximum amperage of the JuiceBox 48 can be adjusted from 16A to 48A in the included app, making it a flexible solution for installations on electrical circuits ranging from 20A to 60A.

  • Spend less time waiting for your EV to charge and more time enjoying the drive

  • Compatible with Teslas and all EVs on the market today and in the future. For Teslas, just use Tesla's provided adapter

  • UL Listed means electrical experts have approved this unit for safe, in-home use

  • Monitor and schedule charging with intuitive mobile app & web portal

  • Dynamic LED lights display WiFi connectivity and charging behavior

  • Schedule your charging times when rates are lower — making your electric vehicle even cheaper to drive. Qualifies for many local utility rebates and incentives

  • Get notified when your car is fully charged, set up a daily charging routine, or get a reminder to plug in when life gets too busy

  • Mounting bracket and built-in cable management make set up and daily charging a breeze

  • Monitor, manage, and control your charger via voice commands on Amazon Echo / Alexa and Google Home

  • Optimize charging times and participate in smart grid programs to reduce emissions

    ENERGY STAR®-certified

    Drive even greener with JuiceNet Green’s Automated Emissions Reductions

  • Participate in the JuicePoints program to get paid for charging your EV

  • Configure two or more JuiceBox charging stations to share a circuit

  • 3-year manufacturer's warranty for use under normal residential operating conditions (please note that the residential warranty is void if the station is used in a non-residential setting)

  • Weatherproof, dust-tight, polycarbonate casing

Specifications

  • Output Power 48A, 11.5kW

  • Input Voltage
    Single phase input: nominal voltage 208-240 VAC

  • Input
    2.5 ft (0.8 m) hardwire conduit & wiring

  • Output Cable
    25-foot SAE J1772 standard plug

  • Dimensions
    7.6” (173 mm) x 18.6” (474 mm) x 5.6” (141 mm)

  • Weight
    17 lbs (7.7 kg)

  • Codes and Standards
    FCC Part 15 Class B, NEC 625 compliant

  • Warranty
    3-year warranty for use under normal residential operating conditions

  • Safety
    UL and cUL Listed

What You Receive

  • In the package, you will receive:
    A JuiceBox 48, featuring:

    • A 25-foot charging cable (also known as a J1772 cable)

    • 2.5 ft (0.8 m) hardwire conduit & wiring

    • NEMA 4X

    • Full smartphone app and online control dashboard to set up and monitor your station

    • Installation guide

    • Wall mounting bracket

    • Security lock with key

Installation

This JuiceBox home charger is hardwired, which means it must be directly fastened to the circuit without using a traditional outlet or plug, and will require installation by a professional electrician. See our installation guide to learn more. JuiceBox 48 is not available as a plug-in unit as required by UL safety standards to ensure reliable, safe use.

You can have your charging station professionally installed by purchasing the JuiceReady Home Installation Service available in certain areas. You can also find a qualified and experienced electrician on the Amazon Home Services website and with Qmerit, a network of pre-qualified EV charging station installers.
